Home ProductsRockfall Catch Fences

Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting

Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting

Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting
Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting

Large Image :  Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting Get Best Price

Product Details:
Place of Origin: China
Brand Name: IDECO
Certification: ISO9001:2008
Model Number: ROCKFALL RING NETS
Payment & Shipping Terms:
Price: USD70 PER SQM
Packaging Details: BULK
Delivery Time: 20 days
Payment Terms: TT,LC, Western Union, MoneyGram
Supply Ability: 20 days for a 20'GP
Detailed Product Description

Wire-Rope Ring net Debris Flow Barrier



Ring nets are used essentially with rockfall barriers due to their strength and minimal need for attention and maintenance once installed. A High Resistance wire (from 140 to 155 daN/mm2) is used and a broigne weaving technique significantly increases resistance by comparison with the standard square mesh design of other nets.



They are braided, which means they are much stronger than ring nets made of wound coils held by clips.
The absence of any visible end rope (these are inserted inside the strand) ensures better energy absorption and greater safety during placing.

The fact that there no visible extremities on the rings (they are inserted into the strand) improves both energy absorption capabilities of the net and the safety of the workers during installation.

Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting 0

Our wire-rope ring nets are available in two different combinations:

- Type 1+4 : 1 ring + 4 peripheral rings for low to average energy impacts

- Type 1+6 : 1 ring + 6 peripheral rings for high energy impacts.



Ring Nets have the highest strengths of any mesh in the rockfall protection Systems range. With high strain performance, Ring Nets are ideal for situations where there is a high risk of dynamic impacts. The nets are also used to face rock slopes featuring large rock masses prone to failure; Ring Nets can accommodate these high local stresses without sustaining damage.



The technical performance of the ring nets has been optimized to provide a balance of strength, weight and flexibility. The performance of the nets is dependent upon wire strand diameters, bundle configurations and the number of connection points to adjacent rings within the panel.

Rockfall Barrier Ring Nets, Slope Rockfall Protection, Railway Slide Catch Fences, Rockfall Wire Mesh Netting 1
