Hexagonal mesh and anchors are used for armouring refractory, anti-abrasive and anti-corrosive linings and are used in the oil, petrochemical, chemical, metallurgical, cement and various other industries. We produce numerous different kinds of hexagonal mesh and anchors to meet the technical specifications of the main process and engineering companies and has considerable experience in the elaboration of construction and assembly drawings, indispensable for facilitating installation. The level of automation achieved in the production process, thanks to the development of technologically advanced machines, enables high qualitative levels to be attained, together with the great flexibility necessary to meet very tight delivery times in emergency situations.
Hexmesh consists of panels in shaped metal plates joined together by a special locking system that guarantees high stiffness even after the panel has been rolled. It is used to armour and support refractory linings, resistant to abrasion and corrosion, applied to the walls of reactors, cyclones, furnaces and vessels. Hexmesh panels can be supplied both flat and cut to size and rolled in accordance with installation drawings issued by the technical office. Flat rectangular panels measuring 2000×1000 mm are always available in stock. Standard panels are made from 19 or 25 mm thick plates, hexagonal cells with or without lances and central or staggered positioning of the lances. The main materials used for the production of hexmesh are AISI 304H, 410S, 310S and carbon steel. A table of materials, complete with chemical analysis and working temperatures can be viewed by clicking on the text to the right of the photographs.
|Material||0Cr18Ni9, 1Cr18Ni9Ti, SS304, SS316, SS310S, A3, 0Cr13, 1Cr13, etc.|
|Gauge||1.0mm / 1.2mm / 1.5mm / 1.8mm /2.0mm / 2.5mm / 3.0mm|
|Aperture||50mm (min 40mm, max 100mm)|
|Panel size||0.96mx1.05m(according to the raw material size)|
|Note||Other dimensions & material are also available upon request|
