Stainless Steel Wire Mesh Fabric for Diagonal Covers with Gold Seam/Silver Seam/Plasma Seam

STAINLESS STEEL DIAGONAL CYLINDER COVERS for fiber cement cylinder moulds, formers, thickeners, dandy rolls, breast rolls, dryer screens and polyester shrinking covers

We manufacture high quality diagonally seamed non-marking cylinder mould covers for many industries such as the fibre-cement, cardboard, paper and pulp, fine cigarette paper or cellulose manufacturers and for the waste paper recycling mills.

Our diagonal fabrics achieve outstanding running times on your cylinders. We supply precisely according your dimensions required and with a seam suitable for your process.

The seams are absolutely non-marking, straight and diagonal gold solder-seam, twisted wire cloth with soldered seam, prepared gold solder seam, plasma seam.

​

We weave an extensive selection of different weaving patterns ranging from 2/cm to 40/cm with aperture sizes from 4.1 to 0.14 mm and up to 9 meter wide.

We also weave:
twill weave 3-shaft

twill weave 4-shaft (2-2 weave)
twill weave (3-1 weave)
herringbone twill weave 4- shaft

plain dutch weave

twill dutch weave

reverse plain and twill dutch weave

multi warp twisted plain weave

multi warp twisted 3-shaft weave
