Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences

It's nice to do business with you April.

—— Abudul Halim

The razor mesh are very good quality.

—— Jaco

I'm Online Chat Now

Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences

China Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences supplier
Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences supplier Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences supplier Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences supplier Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences supplier

Large Image :  Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences

Product Details:

Place of Origin: CHINA
Brand Name: IDECO
Certification: ISO9001:2008
Model Number: DUALSKIN 358 MESH FENCES

Payment & Shipping Terms:

Packaging Details: PALLET
Delivery Time: 20 DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 DAYS PER CONTAINER
Contact Now
Detailed Product Description

Double skin 358 mesh fencing – For a more robust double skinned 358 high security system…



Product Applications

The HiSec DualSkin double skin 358 mesh fencing system has been specifically designed and developed for applications and sites that require a more robust solution than standard 358 mesh.

This double skin 358 mesh fencing system features two layers of the traditional HiSec 358 welded mesh with 76.2mm x 12.7mm open mesh sections.

These double skin 358 mesh panels are welded together with the secondary panel turned 90 degrees to make a very tight mesh 12.7mm x 12.7mm mesh configuration, which is difficult to cut and almost impossible to climb.

The small apertures of the double skin 358 mesh with welds at each intersection eliminates foot and finger holds for people to climb or gain access to the site.

The tight mesh pattern of the double skin 358 mesh makes it almost impossible to pass objects or contraband through the fence into restricted areas and is highly resistant against the use of hand or power cutting tools.

HiSec DualSkin double skin 358 mesh fencing system provides an ideal solution for a wide variety of high security perimeter, integrated solutions and access control applications. Additional fence toppings can also be used to add extra security to the fence line. Matching pedestrian and vehicle gates are also available to compliment the fence line.



Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences

Features & Benefits

  • Secure & discreet system providing maximum security
  • A discreet visual impact on the local environment
  • Vandal resistant, anti-cut, robust wire & weld joints make cutting very difficult using conventional bolt or wire cutters
  • Anti-Climb with no toe or finger holds due to small mesh apertures
  • Good viewing visibility characteristics despite the small mesh aperture
  • One of our highest level security fences
  • 4mm vertical and horizontal wires
  • Available as a complete system
  • A flat panel that gives improved aesthetic appearance
  • Available in a wide range of colour options
  • Available either bolt down, in ground or on wall post options
  • Ideal for use with CCTV cameras
  • For areas where visibility needs to be restricted, upgrades can be added
  • A wide variety of fence toppings can also be supplied
  • Matching pedestrian and vehicle gates are also available

Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences

Technical Information

Panels

  • Wire Diameter of 4mm (4.40mm PVC coated)
  • Apertures of 12.7mm x 12.7mm (centre to centre)
  • Standard Widths of 2515mm
  • Heights of up to 2.5m
  • Weld Strength of 60 – 80%

Posts

  • Panels are bolted onto RHS posts or welded tubular posts

Coating options

  • PVC coating, hot dipped galvanised wire panels, sealed with an adhesion epoxy coating prior to the PVC coating to ensure a perfect bond

Colours

  • Standard colours of Green RAL 6005, Black RAL9005
  • Other colours are available upon request

Quality guaranteed

  • We are an ISO Certified company and the quality of our products is vitally important to our success, therefore all our products meet the highest standards possible
  • Mesh Specification
Height Post Centres Vertical Wire Horizontal Wire Mesh Pattern Post Section
1.80 mtr – 2.50 mtr 2.525 mtr 4mm 4mm 12.7mm x 12.7mm 80mm x 80mm
  • Note: HiSec DualSkin can be applied to any height up to 6 metres

Securi-Mesh Plus Twin 90º 358 Mesh Fences, Double Skin 358 Mesh Security Fencing, Dual Skin Welded HiSec Fences
